A carbine (/ˈkɑrbiːn/ or /ˈkɑrbaɪn/), from French carabine, is a longarm similar to -- but shorter than -- a rifle or musket. Many carbines are shortened versions of full rifles, firing the same ammunition at a lower muzzle velocity due to a shorter barrel length.
The smaller size and lighter weight of carbines makes them easier to handle. They are typically issued to high-mobility troops such as special-operations soldiers and paratroopers, as well as to mounted, supply, or other non-infantry personnel whose roles do not require full-sized rifles.
1.1 Early history: before the 1900s,
1.2 Shorter rifles, shorter carbines: World War I and World War II,
1.3 After World War II,
2 Modern history
2.1 Contemporary military forces,
2.2 Special forces,
3.1 Pistol-caliber carbines (PCC),
3.2 Short barrelled rifles,
3.3 Pistol conversion carbine,
3.4 Other carbines,
4 See also,
5 Further Reading,
Early history: before the 1900s:
Left image: Jean Lepage silex carbine said "du Premier Consul", circa 1800., Right image: Rifling of Lepage carbine.
The carbine was originally a lighter, shortened weapon developed for the cavalry. Carbines were short enough to be loaded and fired from horseback but this was rarely done - a moving horse is a very unsteady platform, and once halted a soldier can load and fire more easily if dismounted, which also makes him a smaller target. The principal advantage of the carbine's length was portability. Troops could carry full length muskets comfortably enough on horseback if just riding from A to B (the practice of the original dragoons and other mounted infantry). Cavalry proper (a 'Regiment of Horse') had to ride with some agility and engage in sword-wielding melees with opposing cavalry so carrying anything long would be a dangerous encumberance. A carbine was typically no longer than a sheathed sabre, both arranged to hang with their tops clear of the rider's elbows and bottoms clear of the horse's legs.
Some sources derive the name of the weapon from the name of its first users--bernarda troopers called "carabiniers", from the French carabine, from the Old French carabin (soldier armed with a musket), perhaps from escarrabin, gravedigger, which derives from scarabee, scarab beetle.
Carbines were usually less accurate and less powerful than the longer muskets (and later rifles) of the infantry, due to a shorter sight plane and lower velocity of bullets fired from the shortened barrel. With the advent of fast-burning smokeless powder, the velocity disadvantages of the shorter barrels became less of an issue (see internal ballistics). Eventually, the use of horse-mounted cavalry would decline, but carbines continued to be issued and used by many who preferred a lighter, more compact weapon even at the cost of reduced long-range accuracy and power.
During the 19th century, carbines were often developed separately from the infantry rifles, and in many cases did not even use the same ammunition, which made for supply difficulties. A notable weapon developed towards the end of the American Civil War by the Union was the Spencer carbine. It had a spring-powered magazine in the stock which held seven rounds. In the late 19th century it became common for a number of nations to make bolt-action rifles in both full-length and carbine versions. One of the most popular and recognizable carbines was the Winchester lever-action carbine, with several versions using revolver cartridges. This made it an ideal choice for cowboys and explorers, who could carry a revolver and a carbine, both using the same ammunition.
Shorter rifles, shorter carbines: World War I and World War II:
In the decades following World War I, the standard battle rifle used by armies around the world had been growing shorter, either by redesign or by the general issue of carbine versions instead of full-length rifles. For example, the Russian Model 1891 rifle with an 800 mm (31.5 inch) barrel was shortened to 730 mm (28.75 in.) in 1930, and to 510 mm (20 in.) in 1938; the German Mauser 98 rifles went from 740 mm (29 in.) in 1898 to 600 mm (23.6 in.) in 1935 as the Karabiner Kurz (K98k or Kar98k), or "short carbine". The barrel lengths in rifles used by the United States did not change between the bolt-action M1903 rifle of World War I and the World War II M1 Garand rifle, but the 610 mm (24 in.) barrel on the M1903 was short for its day. The US M1 Carbine was more of a traditional carbine in that it was significantly shorter and lighter, with a 457.2 mm (18 in. barrel), than the M1 Garand rifle. The M1 Carbine was not a shorter version of the M1 Garand, as was typical for rifles vs. carbines in the 19th century, but a wholly different design firing a smaller, less-powerful cartridge.,
The United Kingdom also developed a "Jungle Carbine" version of their Lee-Enfield service rifle, featuring a shorter barrel, flash suppressor, and manufacturing modifications designed to decrease the rifle's weight. Officially titled Rifle, No. 5 Mk I, it was introduced in the closing months of World War II, but did not see widespread service until the Korean War, the Mau Mau uprising, and the Malayan Emergency.
After World War II:
A shorter weapon was more convenient when riding in a truck, armored personnel carrier, helicopter or aircraft, and also when engaged in close-range combat. Based on the combat experience of World War II, the criteria used for selecting infantry weapons began to change. Unlike previous wars, which were often fought mainly from fixed lines and trenches, World War II was a highly mobile war, often fought in cities, forests, or other areas where mobility and visibility were restricted. In addition, improvements in artillery made moving infantry in open areas even less practical than it had been.
The majority of enemy contacts were at ranges of less than 300 metres (330 yards), and the enemy was exposed to fire for only short periods of time as they moved from cover to cover. Most rounds fired were not aimed at an enemy combatant, but instead fired in the enemy's direction to keep them from moving and firing back (see suppressive fire). These situations did not require a heavy rifle, firing full-power rifle bullets with long-range accuracy. A less-powerful weapon would still produce casualties at the shorter ranges encountered in actual combat, and the reduced recoil would allow more shots to be fired in the short amount of time an enemy was visible. The lower-powered round would also weigh less, allowing a soldier to carry more ammunition. With no need of a long barrel to fire full-power ammunition, a shorter barrel could be used. A shorter barrel made the weapon weigh less and was easier to handle in tight spaces, and was easier to shoulder quickly to fire a shot at an unexpected target. Full-automatic fire was also considered a desirable feature, allowing the soldier to fire short bursts of three to five rounds, increasing the probability of a hit on a moving target.
The Germans had experimented with selective-fire carbines firing rifle cartridges during the early years of World War II. These were determined to be less than ideal, as the recoil of full-power rifle cartridges caused the weapon to be uncontrollable in full-automatic fire. They then developed an intermediate-power cartridge round, which was accomplished by reducing the power and the length of the standard 7.92x57 Mauser rifle cartridge to create the 7.92x33 Kurz (Short) cartridge. A selective-fire weapon was developed to fire this shorter cartridge, eventually resulting in the Sturmgewehr 44, later translated as "assault rifle". After World War II, the USSR would adopt a similar weapon, the AK-47, which became the standard Soviet infantry weapon. The United States during World War II also had the M2 Carbine, a selective-fire version of the M1 Carbine firing a 7.62x33mm cartridge. However, the semi-automatic M1 carbine was produced in a 10-to-1 ratio to the M2.
Although the NATO countries did not adopt an intermediate-power round, they continued the trend toward shorter and lighter magazine-fed battle rifles. NATO adopted the 7.62x51 NATO round (which in reality is only slightly different ballistically to the .308 Winchester and .303 British cartridges), along with several rifles such as the FN FAL and M14.
By the 1960s NATO had adopted the 5.56 NATO cartridge. This round was even lighter and smaller than the Soviet AK-47 cartridge, but possessed higher velocity. In U.S. service, the M16 assault rifle replaced the M14 as the standard infantry weapon, although the M14 continued to be used by designated marksmen.
Lighter carbines came to be adopted as the standard infantry long rifle. What changed was that only a certain number of soldiers now needed to retain longer range weapons, serving as designated marksmen. Development of lighter assault rifles continued, matched by developments in even lighter carbines. At the same time the infantry switched to 5.56 mm weapons, carbines like the AKS-74U (which fired a Warsaw pact 5.45x39 round) and CAR-15 were being developed.
Contemporary military forces:
‹ The template below (Double image) is being considered for deletion. See templates for discussion to help reach a consensus.›
By the 1990s, the US had adopted the M4 carbine, a derivative of the M16 family which fired the same 5.56mm cartridge but was lighter and shorter (in overall length and barrel length), resulting in marginally reduced range and power.
Meanwhile, many armies are experiencing a backlash against carbines and lighter rifles in general, and are equipping selected soldiers, usually called Designated Marksmen, or DM, with higher power rifles. While firing a higher quantity of smaller bullets makes it easier to hit a target (and is therefore good for beginner marksmen), it offers very little to more advanced marksmen. Furthermore, the additional range of the heavier weapons has proven to be necessary in open environments such as deserts. As a result, the focus on more highly trained soldiers equipped with, for example, 7.62 mm NATO firing rifles, such as the U.S. Marine Corps Designated Marksman Rifle variant of the M14, has increased somewhat. A squad of soldiers armed with assault rifles would have a single soldier assigned as DM who would carry a battle rifle for selectively engaging long range targets. The DM differs from the sniper in that the DM moves with his unit, and engages targets at ranges beyond the 500 meter (about 550 yd) effective range of modern assault rifles, but less than the 600 meter (about 650 yd) range which is the optimal engagement range for snipers.
One bastion of the carbine which is unlikely to be unseated is the special forces of the world which need to perform fast, decisive operations. A pistol, though light and quick to operate, is viewed as not having enough power. Consequently, carbines have gained wide acceptance among SOCOM, UKSF and other communities.
The smaller size and lighter weight of carbines makes them easier to handle in close-quarter situations such as urban engagements, when deploying from military vehicles, or in any situation where space is confined. The disadvantages of carbines relative to rifles include inferior long-range accuracy and a shorter effective range. Larger than a submachine gun, they are harder to maneuver in tight encounters where superior range and stopping power at distance are not great considerations. Firing the same ammunition as rifles gives carbines the advantage of standardization over those personal defense weapons (PDWs) that require proprietary cartridges.
The modern usage of the term carbine covers much the same scope as it always had, namely lighter weapons (generally rifles) with barrels less than 457.2 mm (18 inches). These weapons can be considered carbines, while rifles with barrels of 457.2 mm (18 inches) or more are generally not considered carbines unless specifically named so, and depending on the weapon's power. Modern carbines use ammunition ranging from that used in light pistols up to powerful rifle cartridges, with the usual exception of high velocity magnum cartridges. In the more powerful cartridges, the short barrel of a carbine has significant disadvantages in velocity, and the high residual pressure when the bullet exits the barrel results in substantially greater muzzle blast. Flash suppressors and muzzle brakes are common solutions to this problem, which may ease their acceptance.
Pistol-caliber carbines (PCC):
One of the more unusual classes of carbine is the pistol caliber carbine. These first appeared soon after metallic cartridges became common. These were developed as "companions" to the popular revolvers of the day, firing the same cartridge but allowing more velocity and accuracy than the revolver. These were carried by cowboys, lawmen, and others in the Old West. The classic combination would be a Winchester lever action carbine and a Colt revolver in .44-40 or .38-40. During the 20th century, this trend continued with more modern and powerful revolver cartridges, in the form of Winchester and Marlin lever action carbines chambered in .38 Special/.357 Magnum and .44 Special/.44 Magnum.
Modern equivalents also exist, such as the discontinued Ruger Police Carbine, which uses the same magazine as the Ruger pistols of the same caliber, as well as the (also discontinued) Marlin Camp Carbine (which, in .45ACP, used M1911 magazines). The Beretta Cx4 Storm shares magazines with many Beretta pistols, and is designed to be complementary to the Beretta Px4 Storm pistol. The Hi-Point 995 carbine is a cheaper alternative to other pistol caliber carbines in the United States and shares magazines with the Hi-Point C-9 pistol (although many owners report that early Hi-Point C-9 magazines are too short to function in the Model 995 Carbine). Another example is the Kel-Tec SUB-2000 series chambered in either 9 mm Luger or .40S&W which can be configured to accept Glock, Beretta, S&W or SIG pistol magazines. The recent introduction of such products may indicate that there is a growing demand for these companion carbines.
The primary advantages of a pistol caliber carbine are increased accuracy due to the buttstock and longer barrel (and with it, sight radius), relatively low muzzle blast/flash/recoil, higher muzzle velocity and energy of a longer barrel for increased wounding potential and penetration (depending on the particular load used), and (sometimes, but not always) greater adaptability for easily accepting accessories such as optics, weaponlights, and lasers. Furthermore, PCCs may not be as legally restricted as comparable handguns, depending on the jurisdiction.
One less-noted advantage of PCCs is their lower muzzle report compared to more powerful rifles; because they are less noisy when fired, they are less likely to cause permanent hearing damage when fired indoor without hearing protection - this can be an important consideration during home defense. Compared to "regular" carbines/rifles (such as those in .223 and 7.62x39mm), pistol-caliber carbines may suffer from a shorter effective range, more pronounced trajectory, less power, and less effectiveness against body armor.
Short barrelled rifles:
Firearms with shoulder stocks and barrels less than 406 mm (16 in) in length are classified as "short barreled rifles" (under the US National Firearms Act or NFA), and are sometimes restricted in the same way that short barrel shotguns and machine guns are. Because of this, rifles with barrels of less than 406 mm (16 in), or pistols with shoulder stocks, are rare. A list of firearms not covered by the NFA due to their antique status may be found here 1 or due to their Curio and Relic status may be found here 2; these lists includes a number of carbines with barrels less than the minimum legal length and firearms that are "primarily collector's items and are not likely to be used as weapons and, therefore, are excluded from the provisions of the National Firearms Act. " Firearms classified as machine guns are also not subject to the barrel length restriction.
Pistol conversion carbine:
Kits exist which will convert many pistols into carbines by the addition of a shoulder stock; notable examples are the long barrelled Colt Buntline revolver stock, the Mauser C96 "Broomhandle" holster/stock, and various others for models such as the Browning Hi-Power, Luger, Colt M1911, and the Heckler & Koch VP70. Since these stock additions retain the short pistol barrel (as short as 100 mm (3.9 in)) they are highly restricted under the NFA unless the shoulder stocks are of original manufacture for the gun and the gun has been "delisted" as outlined in links 1 & 2 in the paragraph above, as is the case with so-equipped "Broomhandle" Mausers and Lugers. Many pistols which had attachments for the stocks, including rare wartime models, were altered to remove the attachment point.
Another class of carbine is a semi-automatic version of a submachine gun, with an extended barrel, usually just over 406 mm (16.0 in) long, which will escape ban by some "assault weapon" legislation. While functionally identical to pistol-caliber carbines, these are banned in some places as "assault weapons" based on their cosmetic similarity to submachine guns. However, they may not accept certain parts (such as magazines or collapsing stocks) from the submachine guns they resemble. These are a popular compromise for (American) shooters who would like to own a submachine gun but cannot due to local restrictions or the prohibitive cost of buying a civilian legal submachine gun (full automatics or semi-automatics with barrels shorter than 16 inches (410 mm) are restricted under Title II of the National Firearms Act). Many owners may choose to shorten the barrels down to NFA-lengths, and register them as "short barrel rifles" SBRs.
Examples of PCCs that are derivatives of submachine guns but are rifles under Title I (Gun Control Act) include the HK USC (derived from the HK .45ACP UMP submachine gun), the HK94 (derived from the MP5), pistol-caliber AR-15s (such as the Bushmaster Carbon 15 9 mm Carbine), semi-automatic only versions of the Thompson by Auto-Ordnance and the FN PS90 (derived from the FN P90 SMG). Unlike the above-mentioned PCCs, these carbines utilize either magazines from their SMG derivatives, or proprietary magazines (as in the case of the USC).
In some historical cases the term machine carbine was the official title for sub-machine guns, such as the British Sten and Australian Owen guns. The semi-automatic only version of the Sterling submachine gun was also officially called a "carbine". While the original Sterling semi-auto would be classed a "short barrel rifle" under the U.S. National Firearms Act, fully legal long-barrel versions of the Sterling have been made for the U.S. collector market. Wide ThumbClearartFanartBanner User Comments
